Regina Calculation Engine
Public Member Functions | Static Public Member Functions | List of all members
regina::NStandardTriangulation Class Referenceabstract

Describes a triangulation or subcomplex of a triangulation whose structure is well-understood. More...

#include <subcomplex/nstandardtri.h>

Inheritance diagram for regina::NStandardTriangulation:
regina::ShareableObject regina::boost::noncopyable regina::NAugTriSolidTorus regina::NBlockedSFS regina::NBlockedSFSLoop regina::NBlockedSFSPair regina::NBlockedSFSTriple regina::NL31Pillow regina::NLayeredChain regina::NLayeredChainPair regina::NLayeredLensSpace regina::NLayeredLoop regina::NLayeredSolidTorus regina::NLayeredTorusBundle regina::NPluggedTorusBundle regina::NPlugTriSolidTorus regina::NSnapPeaCensusTri regina::NSnappedBall regina::NSpiralSolidTorus regina::NTriSolidTorus regina::NTrivialTri

Public Member Functions

virtual ~NStandardTriangulation ()
 A destructor that does nothing. More...

std::string getName () const
 Returns the name of this specific triangulation as a human-readable string. More...

std::string getTeXName () const
 Returns the name of this specific triangulation in TeX format. More...

virtual NManifoldgetManifold () const
 Returns the 3-manifold represented by this triangulation, if such a recognition routine has been implemented. More...

virtual NAbelianGroupgetHomologyH1 () const
 Returns the expected first homology group of this triangulation, if such a routine has been implemented. More...

virtual std::ostream & writeName (std::ostream &out) const =0
 Writes the name of this triangulation as a human-readable string to the given output stream. More...

virtual std::ostream & writeTeXName (std::ostream &out) const =0
 Writes the name of this triangulation in TeX format to the given output stream. More...

virtual void writeTextShort (std::ostream &out) const
 Writes this object in short text format to the given output stream. More...

Input and Output
virtual void writeTextLong (std::ostream &out) const
 Writes this object in long text format to the given output stream. More...

std::string str () const
 Returns the output from writeTextShort() as a string. More...

std::string toString () const
 A deprecated alias for str(), which returns the output from writeTextShort() as a string. More...

std::string detail () const
 Returns the output from writeTextLong() as a string. More...

std::string toStringLong () const
 A deprecated alias for detail(), which returns the output from writeTextLong() as a string. More...


Static Public Member Functions

static NStandardTriangulationisStandardTriangulation (NComponent *component)
 Determines whether the given component represents one of the standard triangulations understood by Regina. More...

static NStandardTriangulationisStandardTriangulation (NTriangulation *tri)
 Determines whether the given triangulation represents one of the standard triangulations understood by Regina. More...


Detailed Description

Describes a triangulation or subcomplex of a triangulation whose structure is well-understood.

An NStandardTriangulation is generally connected with a real triangulation, i.e., an NTriangulation object, which it describes some portion of.

In general NStandardTriangulation objects cannot be constructed directly, but are instead created through static identification routines such as NStandardTriangulation::isStandardTriangulation(NTriangulation*).

Subclasses corresponding to different families of triangulations do not need to override writeTextShort() since this routine is properly implemented in the base class NStandardTriangulation.

Constructor & Destructor Documentation

regina::NStandardTriangulation::~NStandardTriangulation ( )
inlinevirtual

A destructor that does nothing.

Member Function Documentation

std::string regina::ShareableObject::detail ( ) const
inherited

Returns the output from writeTextLong() as a string.

Returns
a long text representation of this object.
NAbelianGroup * regina::NStandardTriangulation::getHomologyH1 ( ) const
inlinevirtual

Returns the expected first homology group of this triangulation, if such a routine has been implemented.

If the calculation of homology has not yet been implemented for this triangulation then this routine will return 0.

This routine does not work by calling NTriangulation::getHomologyH1() on the associated real triangulation. Instead the homology is calculated directly from the known properties of this standard triangulation.

The details of which standard triangulations have homology calculation routines can be found in the notes for the corresponding subclasses of NStandardTriangulation. The default implementation of this routine returns 0.

The homology group will be newly allocated and must be destroyed by the caller of this routine.

If this NStandardTriangulation describes an entire NTriangulation (and not just a part thereof) then the results of this routine should be identical to the homology group obtained by calling NTriangulation::getHomologyH1() upon the associated real triangulation.

Returns
the first homology group of this triangulation, or 0 if the appropriate calculation routine has not yet been implemented.

Reimplemented in regina::NLayeredSolidTorus, regina::NTriSolidTorus, regina::NLayeredChain, regina::NSpiralSolidTorus, regina::NLayeredTorusBundle, regina::NSnapPeaCensusTri, regina::NLayeredLensSpace, regina::NLayeredLoop, regina::NSnappedBall, regina::NTrivialTri, regina::NL31Pillow, and regina::NLayeredChainPair.

NManifold * regina::NStandardTriangulation::getManifold ( ) const
inlinevirtual

Returns the 3-manifold represented by this triangulation, if such a recognition routine has been implemented.

If the 3-manifold cannot be recognised then this routine will return 0.

The details of which standard triangulations have 3-manifold recognition routines can be found in the notes for the corresponding subclasses of NStandardTriangulation. The default implementation of this routine returns 0.

It is expected that the number of triangulations whose underlying 3-manifolds can be recognised will grow between releases.

The 3-manifold will be newly allocated and must be destroyed by the caller of this routine.

Returns
the underlying 3-manifold.

Reimplemented in regina::NLayeredSolidTorus, regina::NTriSolidTorus, regina::NLayeredChain, regina::NAugTriSolidTorus, regina::NSpiralSolidTorus, regina::NLayeredTorusBundle, regina::NPlugTriSolidTorus, regina::NBlockedSFSTriple, regina::NPluggedTorusBundle, regina::NSnapPeaCensusTri, regina::NLayeredLensSpace, regina::NLayeredLoop, regina::NBlockedSFSLoop, regina::NSnappedBall, regina::NBlockedSFSPair, regina::NTrivialTri, regina::NL31Pillow, regina::NLayeredChainPair, and regina::NBlockedSFS.

std::string regina::NStandardTriangulation::getName ( ) const

Returns the name of this specific triangulation as a human-readable string.

Returns
the name of this triangulation.
std::string regina::NStandardTriangulation::getTeXName ( ) const

Returns the name of this specific triangulation in TeX format.

No leading or trailing dollar signs will be included.

Warning
The behaviour of this routine has changed as of Regina 4.3; in earlier versions, leading and trailing dollar signs were provided.
Returns
the name of this triangulation in TeX format.
static NStandardTriangulation* regina::NStandardTriangulation::isStandardTriangulation ( NComponent component)
static

Determines whether the given component represents one of the standard triangulations understood by Regina.

The list of recognised triangulations is expected to grow between releases.

If the standard triangulation returned has boundary triangles then the given component must have the same corresponding boundary triangles, i.e., the component cannot have any further identifications of these boundary triangles with each other.

Note that the triangulation-based routine isStandardTriangulation(NTriangulation*) may recognise more triangulations than this routine, since passing an entire triangulation allows access to more information.

Parameters
componentthe triangulation component under examination.
Returns
the details of the standard triangulation if the given component is recognised, or 0 otherwise.
static NStandardTriangulation* regina::NStandardTriangulation::isStandardTriangulation ( NTriangulation tri)
static

Determines whether the given triangulation represents one of the standard triangulations understood by Regina.

The list of recognised triangulations is expected to grow between releases.

If the standard triangulation returned has boundary triangles then the given triangulation must have the same corresponding boundary triangles, i.e., the triangulation cannot have any further identifications of these boundary triangles with each other.

This routine may recognise more triangulations than the component-based isStandardTriangulation(NComponent*), since passing an entire triangulation allows access to more information.

Parameters
trithe triangulation under examination.
Returns
the details of the standard triangualation if the given triangulation is recognised, or 0 otherwise.
std::string regina::ShareableObject::str ( ) const
inherited

Returns the output from writeTextShort() as a string.

Python:
This implements the __str__() function.
Returns
a short text representation of this object.
std::string regina::ShareableObject::toString ( ) const
inlineinherited

A deprecated alias for str(), which returns the output from writeTextShort() as a string.

Deprecated:
This routine has (at long last) been deprecated; use the simpler-to-type str() instead.
Returns
a short text representation of this object.
std::string regina::ShareableObject::toStringLong ( ) const
inlineinherited

A deprecated alias for detail(), which returns the output from writeTextLong() as a string.

Deprecated:
This routine has (at long last) been deprecated; use the simpler-to-type detail() instead.
Returns
a long text representation of this object.
virtual std::ostream& regina::NStandardTriangulation::writeName ( std::ostream &  out) const
pure virtual

Writes the name of this triangulation as a human-readable string to the given output stream.

Python:
The parameter out does not exist; standard output will be used.
Parameters
outthe output stream to which to write.
Returns
a reference to the given output stream.

Implemented in regina::NLayeredSolidTorus, regina::NTriSolidTorus, regina::NLayeredChain, regina::NAugTriSolidTorus, regina::NSpiralSolidTorus, regina::NLayeredTorusBundle, regina::NPlugTriSolidTorus, regina::NBlockedSFSTriple, regina::NPluggedTorusBundle, regina::NSnapPeaCensusTri, regina::NLayeredLensSpace, regina::NLayeredLoop, regina::NBlockedSFSLoop, regina::NSnappedBall, regina::NBlockedSFSPair, regina::NTrivialTri, regina::NL31Pillow, regina::NLayeredChainPair, and regina::NBlockedSFS.

virtual std::ostream& regina::NStandardTriangulation::writeTeXName ( std::ostream &  out) const
pure virtual

Writes the name of this triangulation in TeX format to the given output stream.

No leading or trailing dollar signs will be included.

Warning
The behaviour of this routine has changed as of Regina 4.3; in earlier versions, leading and trailing dollar signs were provided.
Python:
The parameter out does not exist; standard output will be used.
Parameters
outthe output stream to which to write.
Returns
a reference to the given output stream.

Implemented in regina::NLayeredSolidTorus, regina::NTriSolidTorus, regina::NLayeredChain, regina::NAugTriSolidTorus, regina::NSpiralSolidTorus, regina::NLayeredTorusBundle, regina::NPlugTriSolidTorus, regina::NBlockedSFSTriple, regina::NPluggedTorusBundle, regina::NSnapPeaCensusTri, regina::NLayeredLensSpace, regina::NLayeredLoop, regina::NBlockedSFSLoop, regina::NSnappedBall, regina::NBlockedSFSPair, regina::NTrivialTri, regina::NL31Pillow, regina::NLayeredChainPair, and regina::NBlockedSFS.

void regina::ShareableObject::writeTextLong ( std::ostream &  out) const
inlinevirtualinherited

Writes this object in long text format to the given output stream.

The output should provide the user with all the information they could want. The output should be human-readable, should not contain extremely long lines (so users can read the output in a terminal), and should end with a final newline.

The default implementation of this routine merely calls writeTextShort() and adds a newline.

Python:
The parameter out does not exist; standard output will be used.
Parameters
outthe output stream to which to write.

Reimplemented in regina::NSnapPeaTriangulation, regina::NGroupPresentation, regina::NHomMarkedAbelianGroup, regina::NNormalSurfaceList, regina::NTetrahedron, regina::NSatRegion, regina::NVertex, regina::NEdge, regina::Dim2Triangle, regina::NTriangle, regina::NLayeredSolidTorus, regina::NHomGroupPresentation, regina::NGenericIsomorphism< dim >, regina::NGenericIsomorphism< 2 >, regina::NGenericIsomorphism< 3 >, regina::NTriangulation, regina::NComponent, regina::NTxICore, regina::NTriSolidTorus, regina::NAngleStructureList, regina::Dim2Edge, regina::NBoundaryComponent, regina::NLayeredChain, regina::Dim2Vertex, regina::Dim2Component, regina::NScript, regina::NAugTriSolidTorus, regina::NSpiralSolidTorus, regina::NSurfaceFilterProperties, regina::NLayeredTorusBundle, regina::NManifold, regina::NPlugTriSolidTorus, regina::NMatrixInt, regina::NBlockedSFSTriple, regina::NPluggedTorusBundle, regina::Dim2Triangulation, regina::NSurfaceSubset, regina::NLayeredLensSpace, regina::NLayeredLoop, regina::NFileInfo, regina::NBlockedSFSLoop, regina::NSnappedBall, regina::NBlockedSFSPair, regina::Dim2BoundaryComponent, regina::NTrivialTri, regina::NL31Pillow, regina::NLayeredChainPair, regina::NText, regina::NSurfaceFilterCombination, and regina::NBlockedSFS.

void regina::NStandardTriangulation::writeTextShort ( std::ostream &  out) const
inlinevirtual

Writes this object in short text format to the given output stream.

The output should be human-readable, should fit on a single line, and should not end with a newline.

Python:
The parameter out does not exist; standard output will be used.
Parameters
outthe output stream to which to write.

Implements regina::ShareableObject.


The documentation for this class was generated from the following file:
